DVD
DVD-Video yes
DVD-R*1/DVD-R DL*1/DVD-RW*1
DVD-Video yes
MP3 yes (DVD-R/ -R DL)
JPEG yes (DVD-R/ -R DL)
Xvid yes (DVD-R/ -R DL)
+R*1/ +R DL*1/ +RW*1
Video yes
CD, CD-R/-RW
CD-DA yes
Video CD yes
SVCD yes
MP3 yes
JPEG yes
Xvid yes
AUDIO SYSTEM
Dolby Digital Decode (2ch)
USB
Slot yes
Front For Playback
USB Standard USB 2.0
Playback
JPEG yes
MP3 yes
Xvid yes
HIGH QUALITY PICTURE
HD Up-Conversion yes
Progressive Scan yes
Video D/A Converter 108 MHz/ 12 bit
HIGH QUALITY SOUND
Audio D/A Converter 192 kHz/ 24 bit
EASY OPERATION
HDMI-CEC yes
Power Resume yes
NETWORKING
Photo Slide Show yes(with MP3 Playback)
CD Ripping yes
TERMINAL
HDMI Output yes
Composite Video Output yes
Analogue Audio Output 2ch
Euro SCART Output yes
OTHERS
Video System PAL/ NTSC
Video S/N More than 53 dB
Audio S/N 90 dB
Dynamic Range 80 dB
Power Supply AC 220-240 V, 50 Hz
Power Consumption(Approx.)
Normal Use 10 W
Standby 0.5 W
DIMENSIONS, WEIGHT
Dimensions (W x H x D) (Approx.)*2 310 x 39 x 204 mm
Weight (Approx.) 1.1 kg
NOTE *1 Discs recorded and finalized on recording devices. *2 Excluding the projecting parts.
WARNING The recording and playback of content on this or any other device may require permission from the owner of the copyright or other such rights in that content. Panasonic has no authority to and does not grant you that permission and explicitly disclaims any right, ability or intention to obtain such permission on your behalf. It is your responsibility to ensure that your use of this or any other device complies with applicable copyright legislation in your country. Please refer to that legislation for more information on the relevant laws and regulations involved or contact the owner of the rights in the content you wish to record or playback. Playability may vary depending on the contents, discs and quality of the recording. For content recorded for your personal use. Specifications are subject to change without notice. Weight and dimensions are approximate.
